Pump and Fugitive Emissions Summits provided networking for Pump Experts
The George Brown Convention Center in Houston was the location for two
simultaneous conferences on pumps and fugitive emissions on June 13 and 14.
A power plant pump workshop on Tuesday included three panelists: Ryan
Kremer of Flowserve, William
(Bill) Livoti of WEG and
Lloyd Aanonsen of General Rubber.
Lloyd
Aanonsen and Carry Helper, Sales - General Rubber
Bill points out that most coal-fired power plants are now cycling and running
most of the time at less than full load. This means pumps are consuming more
energy than they should. Variable speed drives and other measures should be
taken to optimize pump performance at various loads.
Bob McIlvaine gave a speech on high performance pumps for various industries.
Mcilvaine is using its own definition of high performance which includes both
severe and critical service. Severe service is defined as an
application where corrosion, erosion, pressure, or temperature is a concern. It
also includes flow variables such as pumps which must run dry on occasion or are
subject to rapid starts and stops.
Critical service entails impact on the product or the process. Product purity is
critical for many chemical products. Contamination from pump components needs to
be eliminated. In certain cases damage to the product is a concern. The
percentage of solids to be transported can be very high and create challenges
for pump suppliers. The pump efficiency over the flow range is another factor
which can be important.
Unlike general purpose pumps, the evaluation of the total lowest cost of
ownership (LTCO) is challenging and much more important than initial purchase
price when it comes to high performance pumps. Therefore the purchaser needs a
great deal of information about the products available from each supplier. The
supplier needs to thoroughly understand the process in which the pump will be
used. He then needs to determine which of his products will provide the LTCO.
Finally, he needs a way to convince the customer that his product does achieve
the LTCO. The McIlvaine Decision Guide program is designed to accomplish these
goals for both supplier and purchaser.
55 percent of the pumps used in the power industry fall into the high
performance category.
Power Industry -
Pump
Segmentation
High Performance
and Non-High
Performance
Service |
|||
|
% |
% |
% |
Water Intake |
10 |
3 |
7 |
Combustion |
50 |
40 |
10 |
Cooling |
20 |
0 |
20 |
Process |
10 |
8 |
2 |
Wastewater |
10 |
4 |
6 |
Total |
100 |
55 |
45 |
One of the biggest applications in power is the combustion process which
requires boiler feed water pumps with high pressures. Boiler feed water pumps
are found in nuclear, coal and gas turbine combined cycle power plants.
Higher pressure operations are increasing the pressure requirements. A number of
coatings have been applied to these pumps to lengthen life.
The gas turbine combined cycle power plant provides unique problems due to flow
accelerated corrosion (FAC) caused by the constant cycling of many GTCC plants.
Most coal-fired power plants have flue gas desulfurization systems. Some plants
have as many as eight pumps each delivering 50,000 gpm of recycled slurry, which
is both abrasive and corrosive.
The conference was accompanied by an exhibition. One of the suppliers of
coatings and overlays for pumps and valves is
Plasma Coatings.
Jake
Brunsberg, Director of Sales - Plasma Coatings
Fike
supplies explosion and fire protection for power plants.
Stanley Sigle, Director Business Development - Fike
Increasing Flow Control and Treatment Product Gross Margins
The best way to raise prices without losing business is to provide a product
which justifies a higher initial price. To accomplish this you need to:
·
Develop a superior product
·
Convince the customer as to the value
Develop a Superior Product
McIlvaine is currently preparing a Decision Guide on choke valves for oil and
gas applications. These are tough applications and require custom valves
designed for severe service. This is only part of the story according to George
Gorman of the Valve Institute.
The success or failure of a valve rests not only on the valve merits but on how
it is applied. Subsea pipeline valve needs are different from sub-sea
Christmas tree needs. Both are certainly different from the needs at the surface
or on shore. The best valve choice requires detailed knowledge of the unit
operations. When it comes to subsea valves his Institute is dedicated to
providing insights on best choices with separate training courses on subsea
pipeline and Christmas tree valves.
But what are the needs of the long-time valve practitioner?
Does he need an even more robust system?
Input from a number of both supplier and end user experts in the
McIlvaine Insights discussions leads to the conclusion that considerable
analysis and discussion is needed.
Muktiadi Rahardjo of Shell
is the valve and sealing specialist at the Shell Pernis refinery and, based on
this experience, recommends better communication relative to valve issues.
He cited a lack of application knowledge on the part of some vendors and
the inability to utilize the wisdom existing within the end user community.
If you rank the impact of a product on the process, the valve is at the bottom
of the rankings. The product using the valve, e.g. a pump system, will be more
important by virtue of the fact that it typically would include a pump and at
least three valves. The scrubber
company product which includes the valves, pumps, fans, nozzles and scrubbing
tower is obviously of most impact on the process. So, if we agree that process
knowledge is necessary to provide the best valves, then it follows that even
more process knowledge is needed for suppliers of the sub processes What can we
conclude from all of this?
·
IN ORDER TO DEVELOP A SUPERIOR PRODUCT YOU HAVE TO UNDERSTAND THE PROCESS WHERE
THE PRODUCT WILL BE APPLIED.
·
TO CONTINUE TO PROVIDE THE SUPERIOR PRODUCT YOU HAVE TO KEEP UP WITH PROCESS
CHANGES AND NEW REGULATORY AND OTHER CUSTOMER NEEDS.
·
FOCUS YOUR PRODUCT DEVELOPMENT EFFORTS BY PRIORITIZING CUSTOMER NEEDS IN SUCH A
WAY TO MAXIMIZE MARGINS AND PROFITABILITY.
Convince the customer that you have the best product
The best product is defined here as the product with the lowest total cost of
ownership. This definition is
couched in the broadest terms. It
has to take into account the severity of the service but also the criticality.
A peaking gas turbine which cycles a few times per year and can be easily
accessed for maintenance is in a non-critical application compared to the
base-loaded turbine which is in operation 24/7 and cycles hundreds of times per
year.
It is easy to pick the lowest cost product but much more difficult when you have
to assess the lifetime cost based on both severity and criticality.
The first step in creating a convincing program is to understand how
decisions will be and could be made.
·
Decision making is a series of classifications. Whether it is the initial
bidders list, the criteria in the specifications or the ultimate selection the
decision maker is moving from one set of classifications to the next.
·
The elements of the classifications are:
what, which, why and how.
In order to be successful you have to convince some people of just the
“what” and “which” and others you also need to add the “why.”
The “how” is the big challenge which provides credibility to the other
elements.
o
What
are the classifications?: If you
are going to remove SO2, should you consider wet
limestone, wet lime, dry sorbent injection, spray driers, or seawater scrubbing?
o
Which
of the classifications are best?
o
Why
is one the best choice?
o
How
does the product perform uniquely enough to justify the prediction that it will
result in the lowest total cost of ownership?
·
The what, which and why can be communicated through normal sales channels.
The decision guides add clarity.
The problem is that the credibility depends on the “how.”
It is a lot easier to claim the highest efficiency or lowest maintenance
cycle than it is to prove it.
McIlvaine recognizes the challenge of convincing customers that a product has
the lowest total cost of ownership and has a whole program to address it:
4 Lane Knowledge Bridge to the End User
$23 Billion High Performance Pump Revenues Projected for 2017
Nearly half the industrial pumps which will be sold next year will classify as
high performance. According to the
latest forecast in Pumps: World Markets
sales of high performance pumps in 2017 will reach $23 billion.
The criteria for this category are both severe and critical service.
Those pumps which have to be engineered to withstand corrosion, abrasion,
high temperature and pressure are classified as in “severe service.”
Those which must meet high purity and safety requirements such as found
in the food and pharmaceutical industry are classified as in critical service.
High performance pumps are further distinguished by being specially engineered
and not being stocked commodity products.
These pumps are used in many different industries.
The oil and gas applications are the largest with predicted purchases
next year in excess of $6 billion.
A relatively small percentage of municipal wastewater pumps are classified as
high performance. But, since the wastewater pump market is so large, even a
small percentage results in a $3 billion annual high performance pump market.
The chemical and refining industries will also be major purchasers.
The power industry will be a bigger market in Asia than in other regions.
A number of new ultra-supercritical coal-fired power plants are under
construction. Each will have
millions of dollars of high performance pumps.
International suppliers have a large share of the high performance pump market
and a smaller share of the commodity pump market.
It will continue to be easier for an international company to penetrate a
local market with its high performance products rather than its commodity
products.
Greater profits can be reaped from high performance pump sales because of the
higher gross margins. On the
average it is estimated that the gross margin from a high performance pump sale
is 35 percent versus just 25 percent for a commodity pump.
So, despite the smaller market size of the high performance pump market,
the gross profit will be higher.
Each industry can be segmented into five different uses:
Use |
High Performance Needs |
Water Intake |
Extraction from wells, lakes and
streams involves some
pre-treatment.
High performance pumps
are required in some
pre-treatment schemes and where
intake water is corrosive e.g.
some wells. |
Cooling |
Cooling is either once through
or recirculating through cooling
towers.
There are few high
performance pump requirements. |
Combustion |
Power producers and industrial
plants requiring steam and power
need high performance boiler
feedwater pumps. |
Process |
Many process schemes incorporate
high performance pumps to move
or convert a product. |
Wastewater |
Wastewater with abrasive solids
or corrosive chemicals requires
high performance pumps. |
In the power industry, combustion is the largest application due to the boiler
feedwater requirements. In most other industries, the process use is the
greatest. The processes can be
further segmented by function.
Function |
High Performance Pump Needs |
Transport to or from storage |
Medium |
Transport to the next process |
Medium |
Play a role in the product
creation |
High |
Utilities such as lubrication,
hydraulic power, heating and
cooling |
Low and not included in the
forecasts |
Extraction and measurement of
samples |
Low |
The processes which play a role in product creation can be further segmented by
the type of change with which they are involved.
Process |
High Performance Pump Needs |
Examples |
Mixing |
medium |
Fluid-to-fluid or gas-to-fluid
e.g. wastewater pump which moves
and aerates or ammonia pump
which disperses fluid in gas
stream to react with NOx |
Heat/Cool
|
medium |
Cryogenic and LNG high
temperature foods which must not
be damaged by transport |
Separation |
high |
Feed and discharge from
centrifuges, filter presses,
clarifiers. In wet mineral size
reduction and separation, there
are highly abrasive slurries. |
Dehydration/ Evaporation |
high |
Slurries created in
crystallization,
pumps at high pressure to
move liquor through spray drier
nozzles |
Reaction/Absorption |
high |
Varying temperatures, fluid
state and pressure needs of the
reactor or absorber.
Function is often to
recycle and disperse. |
Cleaning or blasting |
high |
Develop pressures to clean scale
from castings and fracture shale |
Disinfection |
medium |
Dispersions of large quantities
of chemicals in liquid |
Displacement |
high |
Water injection to displace oil |
Pump suppliers should seek to understand as much as possible about the
industries, processes and functions within those processes where their pumps
might be used. The pump designers
can provide solutions and not just hardware if they can first understand the
needs. Sales and senior management
need to understand the processes in order to better predict future market
opportunities.
For more information on
N019 Pumps World Market,
click on:
http://home.mcilvainecompany.com/index.php/markets/2-uncategorised/116-n019
Utility E-Alert Tracks Billions of Dollars of New Coal-fired Power Plants on a
Weekly Basis
Here are some headlines from the Utility
E-Alert.
UTILITY E-ALERT
#1277 – June 17, 2016
Table of Contents
COAL – US
EPA to reduce Regional Haze in Utah
Georgia Power will cease operations at all Coal Ash Ponds within Three Years
Arch Coal files Amended Bankruptcy Plan of Reorganization
COAL – WORLD
Mitsubishi Corporation awarded Contract for renovation of Taiwan Power Company's
Boilers and Environmental Facilities
Bukit Asam’s 5,000 MW Power Plant Projects ‘on Track’
Zimbabwe’s US$2 Billion Power Project resumes after Two Years
Additonal Vinh Tan Power Station Plants for Binh Thuan Province, Vietnam
The
41F Utility
E-Alert
is issued weekly and covers the coal-fired projects, regulations and other
information important to the suppliers. It is $950/yr. but is included in the
$3020
42EI Utility Tracking
System
which has data on every plant and project plus networking directories and many
other features.
Daily Project Posting in McIlvaine Oil, Gas, Refining Supplier Program
Oil/Gas/Shale/Refining Market
E-Alert
May 2016 – No. 2
This alert is being issued twice per month for suppliers in flow control and
treatment who are coordinating market research with targeted pursuit of the
larger and longer term orders.
PROJECTS
The following projects each will result in millions of dollars of orders for
flow control and treatment products. Each project has been rated. The
opportunity size is rated from 1-10 with 1 being small and 10 being very large.
The timing for flow and treatment orders has been provided by year, e.g. T 16 =
timing of order is 2016.
Amec Foster Wheeler to Undertake BED Study for $4-$5 Bln Cilacap Refinery
Upgrade Project (08, T20)
Revision Date:
5/26/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
Amec Foster Wheeler, Pertamina, Saudi Aramco, Refining, Engineering, Study,
Design, Upgrade, Production Capacity, Indonesia
Chinese Investors to Build Industrial City in Oman (08, T20)
Revision Date:
5/26/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
325110 - Petrochemical Manufacturing
石化产品生产,
Industrial, Investment, Production Capacity, Refining, Construction, Oman
Abu Dhabi Said to Delay Building Fujairah LNG-Import Plant
Revision Date:
5/19/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Emirates LNG LLC, Mubadala Petroleum, International Petroleum Investment Co,
Onshore, Joint Venture, Import, Regasification, Storage, Delays, UAE
Novatek Still Working on Gydan Peninsula Arctic LNG Plan
Revision Date:
5/19/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Novatek, Project, Liquefaction, Feasibility Study, Development, Russia
FMC Technologies and Technip to Combine: Driving Change by Redefining the
Production and Transformation of Oil and Gas
Revision Date:
5/19/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
FMC Technologies, Technip, Subsea, Onshore, Offshore, Technology, Innovation,
Solutions, MoU, Services, Integration, Production, Manufacture, Transaction,
Growth, Cost Reduction, Merger, USA, France, UK
Jacobs Wins General Engineering Services Contract for SATORP in Saudi Arabia
Revision Date:
5/19/2016
Tags:
325110 - Petrochemical Manufacturing
石化产品生产,
324110 - Petroleum Refineries
石油精炼,
Jacobs Engineering, SATORP, Refining, Engineering, Design, Feasibility Studies,
Saudi Arabia
Wintershall Awards Halliburton Service Contract for Maria Project (T16)
Revision Date:
5/19/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Wintershall, Halliburton Norge, Tools, Subsea Template, Wells, Exploration,
Cementing, Engineering, Development, Drilling, Norway
Jacobs Wins Contract with Mitsubishi for $100 Mln Expansion of South Carolina
Plant (07, T16)
Revision Date:
5/19/2016
Tags:
325110 - Petrochemical Manufacturing
石化产品生产,
Mitsubishi Plastics, Mitsubishi Polyester Film, Jacobs Engineering, Production
Lines, Technology, Engineering, Installation, Operational Efficiency, Expansion,
USA
Cenovus Considering Diluent Recovery Unit at Alberta Rail Terminal
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Cenovus Energy, Diluent Recovery Units, Rail Terminal, Shipping, Production,
Permitting, Construction, Growth, Canada
China's First Private-led $15 Bln Mega-refinery Planned off East Coast (08, T18)
Revision Date:
5/18/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
325110 - Petrochemical Manufacturing
石化产品生产,
Zhejiang Rongsheng Holding Group, Huanqui Contracting and Engineering Corp,
Luoyang Petrochemical Engineering Corp, Construction, Design, Refining,
Environmental Approval, China
NextDecade Files FERC App for Rio Grande LNG, Rio Bravo Pipeline (T18)
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
NextDecade LLC, FERC, Pipeline System, Liquefaction, Export, Application, Site
Evaluation, Construction, Operations, Pipeline, Investment Decision, USA
Nine Gas Transport Offers for Interconnector Greek-Bulgarian Pipeline (T16)
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
DEPA, Bulgaria Energy Holding (BEH), Pipeline, Joint Venture, Investment
Decision, Bidding, Interconnection, Pipeline, Construction, Greece, Bulgaria
Transnet Interested in $25 Bln Investment in African Pipeline, Port Projects
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Transnet, Pipeline, Modernize, Pipeline, Expansion, Investment, Nigeria, Kenya,
Uganda, Tanzania
Idemitsu, AltaGas Suspend Triton LNG Project in Canada
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
AltaGas, Idemitsu Kosan, Joint Venture, Liquefaction, Suspension, Canada
France Studying Possible Ban on Import of U.S. Shale Gas
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Engie, EDF, Hydraulic Fracturing, Import, Ban, Environmental Impact, France
EPA Issues Final Rules Cutting Oil, Natural Gas Methane Emissions
Revision Date:
5/18/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
EPA, Wells, Greenhouse Gas, Regulation, Technology, Drilling, Emissions
Reduction, Methane Emissions Compliance, Monitoring, Inspection, USA
China Enviro Protests Force Halt to Studies for Industrial Park Project
Revision Date:
5/17/2016
Tags:
325110 - Petrochemical Manufacturing
石化产品生产,
Singapore Jurong International Holdings, Nanshan Group, Environmental Standards,
Health, Feasibility Study, Cancellation, Environmental Impact, China
China Firm Wins $620 Mln Contract to Build Cambodia's First Oil Refinery (06,
T16)
Revision Date:
5/17/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
China National Petroleum Corporation, Northeast Refining and Chemical
Engineering Co, Cambodian Petrochemical, Engineering, Construction, Cambodia
America's Newest Refinery in North Dakota Falls Victim to Oil Price Slump
Revision Date:
5/17/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
MDU Resources, Calumet Specialty Products, Review, Demand, Refining, Slowdown,
USA
Saudi's SABIC Eyes U.S. Shale as Top Gas Source for Petrochemicals
Revision Date:
5/17/2016
Tags:
325110 - Petrochemical Manufacturing
石化产品生产,
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
SABIC, Industrial, Growth, Oil-to-chemicals, Coal to Chemical, UK
Saudi Aramco Extends Bid Date for Clean Fuels Project
Revision Date:
5/17/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
Saudi Aramco, Naphtha Hydrotreater, Environmental Standards, Sulfur Removal,
Refining, Bidding, Upgrade, Hydrotreating, Saudi Arabia
Oil Sands Fared Well Through Canada Fire, but Restart a Challenge
Revision Date:
5/16/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
Suncor Energy, Canadian Natural Resources, Syncrude, ConocoPhillips, CNOOC,
Equipment, Restart, Production, Steam Assisted Gravity Drainage, Shutdown,
Canada
EagleClaw Midstream Commissions Toyah I Cryogenic Processing Plant, Toyah II
Plant Is Underway
Revision Date:
5/16/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
EagleClaw Midstream Ventures, Honeywell UOP, Pipeline, Gas Processing, Pipeline,
Gas Gathering, Cryogenic, Compression, USA
Bechtel’s ThruPlus® Delayed Coking Technology Selected for Egyptian Refinery
Revision Date:
5/16/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
Bechtel, Egyptian General Petroleum Corp, Delayed Coking Unit, Design, Delayed
Coking Process, Upgrade, Refining, Egypt
Oil Refiners, Gas Producers Face Higher Costs from Climate Laws
Revision Date:
5/16/2016
Tags:
211111 - Crude Petroleum and Natural Gas Extraction
原油和天然气开采,
324110 - Petroleum Refineries
石油精炼,
Investment Leaders Group, Cost, Utilities, Refining, Gas Processing, Production,
Emissions Reduction, Carbon Pricing, UK, Spain, Germany, Canada, USA
ExxonMobil to Expand Australia’s Altona Refinery to Supply More Diesel, Jet Fuel
(T16)
Revision Date:
5/16/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
ExxonMobil Australia, Refining, Energy Efficiency, Production Capacity,
Australia
Owner of Moroccan Refiner Samir Pledges to Inject $680 Mln to Reverse
Liquidation
Revision Date:
5/16/2016
Tags:
324110 - Petroleum Refineries
石油精炼,
Corral Petroleum Holdings AB, Samir, Financial, Shutdown, Financing, Refining,
Morocco
These projects are covered in more detail and are integrated in a database which
is part of Oil, Gas, Shale and Refining Markets and Projects. This semi-monthly
report is available as part of this service or as a stand-alone subscription.
The Oil/Gas/Shale/Refining E Alert is issued twice per month to
registered subscribers. It is not to be resent to others. Each subscriber must
be registered. The first subscription is $950/yr. and additional subscribers are
$90/yr. The newsletter is free for those who subscribe to
N049 Oil,
Gas, Shale and Refining Markets and Projects.
There is a 30 percent discount for those building an Opportunity Creation
package with one or more of the market reports and one or more of the E Alerts.
-------
You can register for our free McIlvaine Newsletters at:
http://www.mcilvainecompany.com/brochures/Free_Newsletter_Registration_Form.htm.
Bob McIlvaine
President
847-784-0012 ext. 112
rmcilvaine@mcilvainecompany.com
www.mcilvainecompany.com
