NEWS RELEASE                                   JULY 2011

SMR Market Could Top $153 Billion by 2030

The market for small modular nuclear reactors (SMR) could grow rapidly and reach annual sales levels of $153 billion by 2030.  This is the latest forecast in the online N043 Fossil and Nuclear Power Generation: World Analysis and Forecast published by the McIlvaine Company (www.mcilvainecompany.com).

There will be a real market for SMR and all the components. With projects in China and the U.S. at the 125 MW scale slated for operation between 2015 and 2020, there is already significant revenue generation.  One of the outcomes of the Japanese nuclear disaster is a shift in interest from large nuclear power plants to small ones.  Therefore, the revenue stream projections for small nuclear power plants may be more predictable than for the large ones.

The timeline for revenue generation for 100-300 MW projects is split into:

·         preparation,

·         manufacturing ,

·         construction, and

·         startup.

Revenues for consultants and engineers start in the preparation phase and run through startup.  Steel and other raw material revenues would be highest during manufacture and construction. Purchased components should be on site prior to construction. So revenues for pumps and valves would peak a year or two before startup. Some pump and valve revenues are generated when an order is placed and the stream continues through shipment. Additional revenues are generated to assist in startup. There may be an amount withheld until performance guarantees are demonstrated, so this could be well after startup.

Here is the timeline for the B&W Clinch River project and the goal for typical projects once commercialization has been established.

Scheduling and relevance to the revenue streams are shown below:

Segment

Clinch River

 Goal in years prior to start

Preparation

2011-2014

                    4

Manufacturing

2014-2018

                    2

Construction

2016-2019

                    1

Startup

2019-2020

                    0



Argentina’s plan to install a 25-megawatt SMR prototype in 2014 is on schedule. Rosatom Corp, a Russian nuclear company, has said it will sell nearly three SMR equipped barges in 2011. A demonstration high-temperature gas-cooled reactor plant, with twin reactor modules driving a single 210 MWe steam turbine, is slated for startup in 2015 at Shidaowan in China. The B&W Clinch River start is slated for 2020.

There are a dozen or more consortia working on developing SMRs. So even the demonstration plant revenues will be significant.  The B&W prototype is close to startup, so there is modest revenue now. The revenues will likely increase substantially in following years.

Here is a forecast which is based on start date:



SMR Project Timeline

Start Year

2015

2016

2017

2018

2019

2020

2021

2022

Construct

2014

2015

2016

2017

2018

2019

2020

2021

Manufacture

2013

2014

2015

2016

2017

2018

2019

2020

MW

  300

  300

  400

  400

  400

  500

  800

1500

Cost

($ Millions)

1200

1200

1600

1600

1600

2000

3200

6000



If the initial projects prove successful and demonstrate the cost advantages of SMR, then the revenue streams could rise rapidly starting in 2017 when manufacture of vessels and components slated for 2020 startup will peak.

Plate and structural steel could be eight percent of the total cost.  The peak revenues would occur during the manufacturing phase.  So the suppliers would be receiving $96 million in revenues in 2012 rising to $480 million in 2020. In the same time frame, suppliers of pumps and valves would enjoy revenues of $72 million in 2013 rising to $360 million in 2020.

Once the approach is fully commercialized the market could grow rapidly. Variables will include:

·         Cost, safety, and performance of SMRs installed as of 2022

·         The large nuclear program success

·         Environmental perception of new coal-fired power plants as a midterm alternative

·         Cost of carbon sequestration

·         Cost reductions and advances in wind and solar

·         Availability and cost of unconventional gas

·         Price and availability of oil

·         World GDP growth

With an optimum outcome of the above variables, the growth could be 50 percent per year over the 2023-30 time frame.

Start Year

2023

2024

2025

2026

2027

2028

2029

2030

MW High  1000

2,250

  3,375

  5,062

  7,593

11,390

17,085

  25,627

  38,441

 Revenues

 ($ millions)

9,000

13,500

20,250

30,375

45,562

68,343

102,508

153,764

MW Low

1000

1,650

  1,815

  1,996

 2,196

  2,415

   2,656

    2,921

    3,213

Revenues

6,600

  7,260

  7,894

 8,683

  9,660

10,624

  11,686

  12,855



With a relatively poor outcome of developments relative to the above variables the growth could be 10 percent per year.  With the optimum outcome revenues would reach $153 billion/yr in 2030.  The manufacturing revenue would be two years ahead or 2028 in the above chart.

The poor outcome of just under $13 billion in revenues in 2030 is by no means the worst outcome.  If developments relative to several of the variables are very negative, the market could evaporate. If an accident of significant magnitude or several accidents of modest magnitude would occur, the market would be greatly impacted.

There is the possibility of a market which is even bigger than the $153 billion. The reason is that even with the optimum scenario, the SMR installed capacity will only be a few percent of the total world electrical capacity.  The present installed generating capacity is 4,000,000 MW. An additional 2,000,000 MW will be added to world generating capacity by 2030. In addition, another 2,500,000 MW of capacity will be replaced.

So net additional capacity over the 2011-30 period will be 4,500,000 MW.  The optimistic scenario only assumes that 2.5 percent of this additional capacity will be SMR.  There is the potential for revenues far beyond the forecast if SMR were to become the preferred energy generation option.

Revenues by Year for Small Modular Reactors (SMR) Worldwide ($ Million)
